General features
Mullard model MUS12
|
Radio type |
Mains powered table radio |
|
Circuit type |
Superheterodyne, 452kHz IF with delayed AVC |
|
Dimensions |
mm, kg |
|
Cabinet |
Bakelite, cloth grille, printed glass dial |
|
Loudspeaker |
200mm, moving coil, permanent magnet |
|
Main controls |
Volume/on-off, tone, tuning, waveband switch |
|
Connections |
Antenna, ground |
|
Power |
AC or DC, 110 or 220V, W |
Wave
bands
|
LW |
|
|
MW |
|
|
SW |
|
Circuits
and Tubes
|
Oscillator and mixer |
CK1 octode |
|
IF amplifier |
CF3 remote cutoff pentode |
|
Detector, AVC and audio power amplifier |
CBL1 double diode - 9W pentode |
|
Rectifier |
CY1 indirectly heated power diode |
|
Heater current regulator |
C1 resistance tube |
