Philips
model BX465A
General
features
|
Circuit type |
Superheterodyne, 452kHz IF with
delayed AVC |
|
Dimensions |
|
|
Cabinet |
Bakelite, cloth grille behind
Bakelite ornaments, external printed glass dial. |
|
Loudspeaker |
150mm, moving coil, permanent
magnet |
|
Main controls |
Tone, volume/on-off, tuning,
waveband switch. |
|
Extra controls |
PU switch actuated by jack plug in
the PU socket. |
|
Connections |
Antenna, ground, PU, external
loudspeaker |
|
Power |
AC, 110 to 245V in 6 steps, 54W |
|
Country of origin |
The Netherlands |
Wave
bands
|
MW |
170- 560m |
|
SW |
43.7- 140m |
|
SW |
13.5- 43.7m |
Circuits
and Tubes
|
RF preamplifier |
EF22 remote cutoff pentode |
|
Oscillator and mixer |
ECH21 triode-heptode |
|
IF amplifier and audio amplifier |
ECH21 triode-heptode |
|
Audio power amplifier, detector
and AVC |
EBL21 11W pentode-duodiode |
|
Rectifier |
AZ1 dual power diode |
